22.8.3 Sampler MIDI CC Mapping Chart



Sample/Track Parameters:


Default Mapping


Sample - Level


CC#071


Sample - Panorama


-


Sample - Accent Amount


CC#037


Sample - Start


CC#073


Sample - Length


CC#036


Sample - Pitch


CC#079


Sample - Speed


-


Sample - Pitch/Speed Independent


-


Sample - Roll


CC#072


Sample - Roll-Internal Accent ON/OFF


CC#075


Sample - Normalize ON/OFF


CC#056


Sample - Reverse ON/OFF


CC#107


Sample - Fill-in Mode


CC#054


Sample - Fill-in Hold ON/OFF


CC#055



Filter Parameters:


Default Mapping


Filter - Type (LP12/HP12/LP24/HP24/BP/NP/MoogLP/MoogHP)


CC#074


Filter - Cutoff Frequency


CC#042


Filter - Resonance (also Bandwidth for BP/NP)


CC#044



Mod Env Parameters:


Default Mapping


Mod Env - Target


CC#028


Mod Env - Depth


CC#029


Mod Env - Reverse ON/OFF


CC#108


Mod Env - Type (Lin/Exp)


CC#109



LFO Parameters:


Default Mapping


LFO - Rate


CC#019


LFO - Waveform


CC#020


LFO - Target


CC#021


LFO - Depth


CC#022


LFO - Sync ON/OFF


CC#081


LFO - Keyboard Sync ON/OFF


CC#082


LFO - Invert ON/OFF


-



General Track Parameters:


Default Mapping


Shuffle ON/OFF


CC#010


Channel: FX Send


CC#118


Channel: FX Input


CC#119


Channel: Solo ON/OFF


CC#011


Channel: Mute ON/OFF


CC#012


Channel: Volume


CC#113


Channel: Panorama


CC#114



Channel Parametric EQ Parameters:


Default Mapping


Channel: Low EQ - ON/OFF


-


Channel: Low EQ - Shelf/Peak


-


Channel: Low EQ - Frequency


-


Channel: Low EQ - Q


-


Channel: Low EQ - Gain


-


Channel: Mid EQ - ON/OFF


-


Channel: Mid EQ - Frequency


-


Channel: Mid EQ - Q


-


Channel: Mid EQ - Gain


-


Channel: High EQ - ON/OFF


-


Channel: High EQ - Shelf/Peak


-


Channel: High EQ - Frequency


-


Channel: High EQ - Q


-


Channel: High EQ - Gain


-


Channel: EQ - Bypass ON/OFF


-


Channel: EQ - Out


-



Channel Insert FX1 Parameters:


Default Mapping


Channel: INS FX1 - Param1


-


Channel: INS FX1 - Param2


-


Channel: INS FX1 - Param3


-


Channel: INS FX1 - Param4


-


Channel: INS FX1 - LFO ON/OFF


-


Channel: INS FX1 - LFO Waveform


-


Channel: INS FX1 - LFO Invert ON/OFF


-


Channel: INS FX1 - Envelope Follower ON/OFF


-


Channel: INS FX1 - Sync ON/OFF


-


Channel: INS FX1 - Type


-


Channel: INS FX1 - Bypass ON/OFF


-



Channel Insert FX2 Parameters:


Default Mapping


Channel: INS FX2 - Param1


-


Channel: INS FX2 - Param2


-


Channel: INS FX2 - Param3


-


Channel: INS FX2 - Param4


-


Channel: INS FX2 - LFO ON/OFF


-


Channel: INS FX2 - LFO Waveform


-


Channel: INS FX2 - LFO Invert ON/OFF


-


Channel: INS FX2 - Envelope Follower ON/OFF


-


Channel: INS FX2 - Sync ON/OFF


-


Channel: INS FX2 - Type


-


Channel: INS FX2 - Bypass ON/OFF


-
