13.4.4 Generate Parameter Automation


Generate Parameter Automation is used to create Automation curves based on the following waveforms (for one or more Parameters):


Triangle


Sawtooth


Pulse (Square wave, fixed at 50% pulse with)


Triple Peak (a combination a smooth Sawtooth approximated Sine and a 3 times faster running Sine wave)


Sine


All waveforms are invertible.


Use the Lower Limit and Upper Limit sliders to define the range of the generated Automation curve.



Note: Generate Parameter Automation is only supported for Faders, not for Buttons


Generate Parameter Automation is linked with Auto-Clone Bars:

If Auto-Clone Bars is enabled, the Automation will only be generated for the current bar. The generated Automation will then be copied to the ‘auto-cloned bars’ (depending on the clone rule).

(see also Chapter: Pattern Sequencer > The Auto-Clone Bars feature on the Position Controls)
